● 2000W permanent magnet motor, efficient 2-speed transmission 30 rpm and 15 rpm no load.
● Reinforced gearbox, 20CrMn Ti, 40Cr material with special heat treatment, provides improved
 machine service life and precision.
● Heavy-duty proven performance on threading and cutting.
● Self-centering Cutter.
● 5 flute cone reamer, high efficiency debur on tube.
● Easily replaceable clamping jaws.
● New epoxy powder coating.
● G.W./N.W.: 132/112Kg
● MEAS: 96x65x61cm

Standard Equipment:
Supplied with 1 Profiling Die Head 1/2”-2” and 1 Profiling 2.1/2”-4” Die Head,
right Dies sets (1/2”-3/4”), (1”-2”) and (2.1/2”-4”), 4 legs, 1 cutting oil,
1 cutting oil canister and one set of mounting tools.

Code	Voltage	Power	DiesType	Remarks
100Y20	220V 50/60Hz	2000W	BSPT
100Y25	220V 50/60Hz	2000W	NPT
100Y10	110V 50/60Hz	2000W	BSPT
100Y15	110V 50/60Hz	2000W	NPT
