Features
Mini- Smallest and lightest crimp tool on the market.
Agile-Compact measures with 350°rotatable head, suitablefor tight work area,
Stability- Waterproof, dustproof, anti-metal fillings, anti-impact and vibrate.
Ergonomic-Optimized design for balance and control.
Professional-Professional tool for the highest demands
Simple-One-handed operation for reach and ease of use.
Weight (with battery). 2.6Kg
Dimensions: 428x120x80mm

Technical Data
Capacity                     up to 28mm $tainless steel pipe, copper pipe;up to 35mm Plastic pipe, Multi-layer composite pipe
Ram force                    19KN
Stroke                       30mmm
Rated power                  280W
Press cycle time             2.5-5s
Press cycle/charge           180 cycles(DN20 stainless steel)
Semvice interval             10000 cycles
Voltage/capacity             18V/2.0Ah
Charging time                Approx.40 mins
Charging voltage             AC 100V~240V;50~60Hz
Package                      Plastic box

Accessories
Crimping dies                  10-16,25-35,50-70,95,120,150,185,240mm2
Battery                        2pcs
Charger                        1pc
Sealing ring of cylinder       lset
Sealing ring of safety valve   lset
