Features
Lightweight and balanced for control and comfort
Forward-positioned handle for stability
3500 Swivelling barrel easy access to connections
Automatic retraction when crimp is completed
Ergonomic designed to help you easily work inthe most difficult jobsite conditions
Quality for the highest demands
OLED display shows battery percentage,working cycles, fault code, maintenance note
Weight (with battery): 6.0kg
Dimensions: 365x330x75mm

Technical Data
Ram force              6OKN
Stroke                 30mm
Oil capacity           240ml
Max crimping           Cu 300mm/Al 240mm
Cycle time             2.5~5s (Cu 150 mm*)
Cycles/charger         Approx.300 cycles(Cu 150 mm*)
Valtage/capacity       18v/4.0Ah
Charging time          Approx.80 mins
Charging voltage       AC 100V~240V;50~60Hz
Package                Plastic box

Accessories
Crimping dies                   16,25,35,50,70,95,120,150,185,240,300mm
Battery                         2pcs
Charger                         1pc
Sealing ring of cylinder        1set
Sealing ring of safety walve    lset
