● 1300W induction motor, 36 rpm no load.
● Reinforced gearbox, 20CrMn Ti, 40Cr material with special heat treatment, provides improved
● machine service life and precision.
● Heavy-duty proven performance on threading and cutting.（1/2"-2")
● Self-centering Cutter.
● 5 flute cone reamer, high efficiency debur on tube.
●Easily replaceable clamping jaws.
● New epoxy powder coating.
●G.W./N.W.: 75/65Kg.
●MEAS: 74×48×53cm.
●Standard Equipment:
●1 Profiling Die Head 1/2”-2”, right Dies sets (1/2”-3/4”) and (1”-2”), 3 legs, 1 cutting oil, 1 cutting oil canister and one set of mounting tools.

Code	Voltage	Power	Dies Type	Remarks
50F20	220V 50/60Hz	1300W	BSPT
50F25	220V 50/60Hz	1300W	NPT
50F10	110V 50/60Hz	1300W	BSPT
50F15	110V 50/60Hz	1300W	NPT
