● Quick-opening Die Head, easily replaceable pipe Dies or bolt Dies.
● Suitable for right 1/2”-2” pipe threading or M10-M33 bolt threading.
● Single phase, all-purpose motor, induction motor., 28rpm no load
● Easily replaceable clamping jaws.
● Easily replaceable clamping jaws.
● G.W./N.W.: 80/70Kg
● MEAS: 74×48×53cm
● Standard Equipment:
● 1 quick-opening Die Head 1/2”-2”, right Dies sets (1/2”-3/4”) and (1”-2”) or bolt Dies sets M10-M33, 3 legs, 1 cutting oil, 1 cutting oil canister and 1 set of mounting tools.
|
Code |
Voltage |
Power |
Dies Type |
Remarks |
|
50E20 |
220V 50/60Hz |
750W |
BSPT |
1/2”-2” |
|
50E22 |
220V 50/60Hz |
750W |
M |
M10-M33 |
|
50E25 |
220V 50/60Hz |
750W |
NPT |
1/2”-2” |
|
50E10 |
110V 50/60Hz |
750W |
NPT |
1/2”-2” |
|
50E12 |
110V 50/60Hz |
750W |
M |
M10-M33 |
|
50E21 |
220V 50/60Hz |
900W |
BSPT |
1/2”-2”, 5 flute cone Reamer |
|
50E23 |
220V 50/60Hz |
900W |
M |
M10-M33, 5 flute cone Reamer |
|
50E11 |
110V 50/60Hz |
900W |
NPT |
1/2”-2” , 5 flute cone Reamer |
|
50E13 |
110V 50/60Hz |
900W |
M |
M10-M33, 5 flute cone Reamer |
