| Code | HYQD-5T | HYQD-10T | HYQD-20T | HYQD-30T | HYQD-50T |
|---|---|---|---|---|---|
| Body Height | 220mm | 265mm | 285mm | 305mm | 353mm |
| Claw down position | 19mm | 20mm | 22mm | 29mm | 40mm |
| Lifting Height | 120mm | 150mm | 160mm | 160mm | 160mm |
| Bottom Size | 225×160mm | 245×175mm | 265×200mm | 310×225mm | 380×300mm |
| Claw Size | 54×55mm | 65×65mm | 65×85mm | 65×100mm | 75×120mm |
| Claw Capacity | 2.5T | 5T | 10T | 15T | 25T |
| Top Capacity | 5T | 10T | 20T | 30T | 50T |
| G.W/N.W | 13/12kg | 20/18kg | 30/28kg | 44/39.5kg | 82/77kg |
| MEAS | 28.5×23×28.5cm | 32.5×25.5×34.5cm | 36×27.6×37.3cm | 40×29×39cm | 42×36×42cm |
